4-point diamond mount

Thanks Charlie / Rob / Lynn,

That helps a lot. I will think about the diamond style mount and see how we can make it work with our design.

I trust that in your designs all four points are hard mounted to the chassis frame and are not mounted in ‘series’ the way a universal joint would be with the 2 lateral pivots being attached ‘after’ the 2 longitudinal?

Do any of you have any damping / shock absorbers in any direction, the way Doug has built? Or is that not necessary once you introduce the fourth point?

ROB – I’d love to see some pics if it’s not too much trouble.

Thanks guys!

jayshapiro
